VW GOLF VII Variant (BA5, BV5)

1.6 TDI (81 kW / 110 CV) 05/13 - 03/17

Brake discs

Diameter
276mm
Thickness
24mm
Height
49mm
Number of holes
5
Brake disc type
Ventilated
Centering
65mm
Minimum Brembo Xtra brake disc thickness: 21,8 mm
Min. thickness
21mm
Units per box
2
Front
axle
for PR number:1ZF
for PR number:1ZF
09.C547.11
Prime
EAN code 8020584227220
Brembo brake disc equivalent to the original with UV anti-corrosion treatment.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
High carbon
Anti-corrosion
Fastening screws
09.C547.75
Max
EAN code 8020584320211
Brembo Max brake disc with grooves on the braking surface for faster braking.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
High carbon
Anti-corrosion
Fastening screws
09.C547.1X
Xtra
EAN code 8020584317044
Brembo Xtra brake disc with perforated braking surface for improved fading resistance.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
High carbon
Anti-corrosion
Fastening screws
Diameter
288mm
Thickness
25mm
Height
50mm
Number of holes
5
Brake disc type
Ventilated
Centering
65mm
Minimum Brembo Xtra brake disc thickness: 22,8 mm
Min. thickness
22mm
Tightening torque
120Nm
Units per box
2
Front
axle
for PR number:1ZE;1ZP
for PR number:1ZE;1ZP
09.9145.11
Prime
EAN code 8020584024287
Brembo brake disc equivalent to the original with UV anti-corrosion treatment.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Anti-corrosion
Fastening screws
09.9145.75
Max
EAN code 8020584015162
Brembo Max brake disc with grooves on the braking surface for faster braking.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
Anti-corrosion
Fastening screws
09.9145.1X
Xtra
EAN code 8020584212615
Brembo Xtra brake disc with perforated braking surface for improved fading resistance.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
Anti-corrosion
Fastening screws
Diameter
312mm
Thickness
25mm
Height
50mm
Number of holes
5
Brake disc type
Ventilated
Centering
65mm
Minimum Brembo Xtra brake disc thickness: 22,8 mm
Min. thickness
22mm
Tightening torque
120Nm
Units per box
2
Front
axle
for PR number:1ZA;1ZD
for PR number:1ZA;1ZD
09.9772.11
Prime
09.9772.10 without paint
EAN code 8020584018286
Brembo brake disc equivalent to the original with UV anti-corrosion treatment.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
High carbon
Anti-corrosion
Fastening screws
09.9772.75
Max
EAN code 8020584029725
Brembo Max brake disc with grooves on the braking surface for faster braking.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
High carbon
Anti-corrosion
Fastening screws
09.9772.1X
Xtra
EAN code 8020584212677
Brembo Xtra brake disc with perforated braking surface for improved fading resistance.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
High carbon
Anti-corrosion
Fastening screws
Diameter
272mm
Thickness
10mm
Height
48mm
Number of holes
5
Brake disc type
Solid
Centering
65mm
Minimum Brembo Xtra brake disc thickness: 8,5 mm
Min. thickness
8mm
Tightening torque
120Nm
Units per box
2
Rear
axle
for PR number:1KE
for PR number:1KE
08.B413.11
Prime
08.B413.10 without paint
EAN code 8020584031483
Brembo brake disc equivalent to the original with UV anti-corrosion treatment.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Anti-corrosion
Fastening screws
08.B413.75
Max
EAN code 8020584319697
Brembo Max brake disc with grooves on the braking surface for faster braking.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
Anti-corrosion
Fastening screws
08.B413.1X
Xtra
EAN code 8020584212332
Brembo Xtra brake disc with perforated braking surface for improved fading resistance.
Brembo quality
ECE-R90 certificate
Performance
Sports driving
Sporty look
Anti-corrosion
Fastening screws

UPGRADE brake discs

Diameter
288mm
Thickness
25mm
Height
50mm
Number of holes
5
Brake disc type
Solid
Centering
65mm
Min. thickness
22,8mm
Tightening torque
120Nm
Units per box
0
Front
axle
for PR number:1ZE;1ZP
for PR number:1ZE;1ZP
59.E114.33
SPORT | TY3 brake disc
Product currently being developed
EAN code 8020584605042
Ideal both for road use as well as high performance driving.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look
Diameter
312mm
Thickness
25mm
Height
58mm
Number of holes
5
Brake disc type
Solid
Centering
65mm
Min. thickness
22,8mm
Tightening torque
120Nm
Units per box
0
Front
axle
for PR number:1ZA;1ZD
for PR number:1ZA;1ZD
59.E114.37
SPORT | TY3 brake disc
Product currently being developed
EAN code 8020584605080
Ideal both for road use as well as high performance driving.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look
Diameter
272mm
Thickness
10mm
Height
48mm
Number of holes
5
Brake disc type
Solid
Centering
65mm
Min. thickness
8,5mm
Tightening torque
120Nm
Units per box
0
Rear
axle
for PR number:1KE
for PR number:1KE
59.E115.26
SPORT | TY3 brake disc
Product currently being developed
EAN code 8020584605998
Ideal both for road use as well as high performance driving.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look

Brake pads

Width
146mm
Thickness
17mm
Height
62mm
Braking system
Teves
Wear indicator
Electric
WVA number
22036, 22037, 22035
FMSI
D1968 9193
Accessories
With piston clip
Front
axle
for PR number:1ZF
for PR number:1ZF
P 85 137
Prime
EAN code 8020584112502
Brake pad with the performance, comfort and reliability of a Brembo product.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
P 85 137X
Xtra
EAN code 8020584069448
Brembo Xtra brake pad suitable for Brembo perforated and grooved discs.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Sports driving
Width
160mm
Thickness
20mm
Height
65mm
Braking system
TRW
Wear indicator
Electric
WVA number
25683, 25684
FMSI
D1760 8989
Accessories
With brake caliper bolts
Front
axle
for PR number:1ZE;1ZP
for PR number:1ZE;1ZP
P 85 126
Prime
EAN code 8020584103999
Brake pad with the performance, comfort and reliability of a Brembo product.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
P 85 126X
Xtra
EAN code 8020584069417
Brembo Xtra brake pad suitable for Brembo perforated and grooved discs.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Sports driving
Width
123mm
Thickness
16mm
Height
56 - 61 mm
Braking system
Teves
Wear indicator
Without
WVA number
25009, 25011
FMSI
D1761 8996
Rear
axle
for PR number:1KJ;1KV;1KY
for PR number:1KJ;1KV;1KY
P 85 124
Prime
EAN code 8020584103975
Brake pad with the performance, comfort and reliability of a Brembo product.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
P 85 124X
Xtra
EAN code 8020584069394
Brembo Xtra brake pad suitable for Brembo perforated and grooved discs.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Sports driving
Width
123mm
Thickness
16mm
Height
56 - 61 mm
Braking system
Teves
Wear indicator
Without
WVA number
25008, 25010
FMSI
D1761 8990
Rear
axle
for PR number:1KE
for PR number:1KE
P 85 125
Prime
EAN code 8020584103982
Brake pad with the performance, comfort and reliability of a Brembo product.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
P 85 125X
Xtra
EAN code 8020584069400
Brembo Xtra brake pad suitable for Brembo perforated and grooved discs.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Sports driving

Brake pad accessories

Length
170mm
Type
Wear indicator
Front
axle
for PR number:1ZE;1ZP
for PR number:1ZE;1ZP
A 00 492
PRIME
EAN code 8020584111062
Accessories for Brembo brake pads. Reliability of an original Brembo product.
OE-equivalent
Brembo quality
Safety
Quick assembly

UPGRADE brake pads

Width
160mm
Thickness
20mm
WVA number
25683, 25684
Front
axle
for PR number:1ZE;1ZP
for PR number:1ZE;1ZP
07.B314.93
SPORT | HP2 brake pads
EAN code 8020584603147
Brake pad with constant braking performance even in extreme conditions.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look
Width
123mm
Thickness
16mm
WVA number
25008, 25010
Rear
axle
for PR number:1KE
for PR number:1KE
07.B315.41
SPORT | HP2 brake pads
EAN code 8020584603116
Brake pad with constant braking performance even in extreme conditions.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look
Width
123mm
Thickness
16mm
WVA number
25009, 25011
Rear
axle
for PR number:1KJ;1KV;1KY
for PR number:1KJ;1KV;1KY
07.B315.42
SPORT | HP2 brake pads
EAN code 8020584604410
Brake pad with constant braking performance even in extreme conditions.
OE-equivalent
Brembo quality
ECE-R90 certificate
Safety
Performance
Comfort
Sports driving
Sporty look
Did you find this content interesting?
Exceeding the standards

Brembo Prime Brake Fluid

The Brembo Prime Brake Fluid products pass the standards applied for class 4, 5.1 and 6 brake fluid.
The product offers greater resistance against Vapour Lock, ensuring braking efficiency even at low temperatures.Thanks to the excellent corrosion- and oxidation-resistant properties, the Brembo brake fluids also make it possible to achieve long-term protection against alteration of fluid chemical/physical properties when in the operating circuit, thus keeping it intact.
Check the compatibility of your braking system with the brake fluid selected in the service manual of your car.
Click here to download the Safety Data Sheet for the Brembo brake fluid
XTRA line<br />BRAKE FLUID

XTRA line
BRAKE FLUID

Xtra brake fluid is the ideal solution that combines the high resistance to high temperatures of the DOT 5.1 fluid and the low viscosity of the DOT 4 low viscosity.
Viscosity is an important factor for the correct operation of the braking system, above all in modern vehicles with anti-locking systems (ABS) and electronic systems for traction and stability control (ESP).
In these systems, the fluid flows through the control mechanisms (generally valves with very limited passages) and it is of fundamental importance for the liquid to be very fluid precisely because of the need for a precise and immediate transfer.
Due to these characteristics, it is the liquid that Brembo suggests in combination with the products of the Xtra range (discs, pads, calipers), for sporty and safe road driving.
Check the compatibility of your braking system with the brake fluid selected in the service manual of your car.
Click here to download the Safety Data Sheet for the Brembo brake fluid
